Box Two Oversized M30-P Crankset

All Box One and Two cranksets are engineered and crafted using our Oversized Technology. we all know that there is no use pushing hard on your pedals if you can’t deliver most of that power to the rear wheel. While creating our cranks, we were obsessed with Power delivery AKA pedalling stiffness. To reduce lateral deflection at the bottom bracket we chose to enlarge the spindle and the crank arm’s interfaces. We robbed material from unloaded sections to reinforce these zones of high stress. Not only are you going to be more efficient with power delivery, but you’ll also feel the instant response of acceleration. Seen through another lens, less energy will be required to achieve the same elapsed time.

Key differences: The Box Two M30-P crankset is a slightly less acute embodiment of our Oversized technology for cranksets. We squeeze in a show-stopping Praxis™ made 30mm that’s been cold-forged from 7075 T6 aluminum and then painstakingly ground to precision. You’ll be relieved to know this will all fit in a European bottom bracket. The crank arms and spider are poached from the Box One M35 model and as a result, you get all that hollow-forged generosity to help you put that power down. These cranks are engineered for the larger-sized racers.





Important Notes:



  • BB86 frames require Praxis™ part 86-4001B or 86-4001W.
  • BB30/PF30 frames require Praxis™ part 68-4001R or 68-5401R.
  • T47 frames require Praxis™ part 47-0000.



Do not use pedal washers when installing pedals onto these cranks. M30-P cranks were designed to be used without pedal washers.

Specifications

  • Material Hollow-Forged & CNC 7075 T-6 Aluminium
  • Spindle CNC Turned 7075 T-6 Aluminium
  • Crank Arm Length 172.5, 175, 177.5 and 180mm
  • Chainline 44.5mm
  • Q-Factor 163mm
  • Bottom Bracket BSA 30mm Included
  • Colour Black
Box Two Oversized M30-P Crankset
Box Two Oversized M30-P Crankset
Click image to enlarge

To find out where to buy  Click Here

Description Colour Size Wt(g) Part No. Stock Lvl Unit RRP Pack Qty
TWO M30 Cranks, 104BCD, 4-bolt, Hollow Forged 7075-T6 Alloy, CrMo Spindle, inc. 30mm External BB setBlack172.5mm800CKBX2M30JK£399.99Each
TWO M30 Cranks, 104BCD, 4-bolt, Hollow Forged 7075-T6 Alloy, CrMo Spindle, inc. 30mm External BB setBlack175mm810CKBX2M30KK£399.99Each
TWO M30 Cranks, 104BCD, 4-bolt, Hollow Forged 7075-T6 Alloy, CrMo Spindle, inc. 30mm External BB setBlack177.5mm820CKBX2M30LK£399.99Each
TWO M30 Cranks, 104BCD, 4-bolt, Hollow Forged 7075-T6 Alloy, CrMo Spindle, inc. 30mm External BB setBlack180mm830CKBX2M30MK£399.99Each
  • Good stock levels
  • Low stock levels, Qtys may not be available
  • +24h Components are available, add 24/48hrs for assembly
  • Special Order Currently non-stock item, contact us for info
  • Out of stock. Expected availability date will be displayed if known.
  • Discontinued. This product is no longer available.
  • M Mixed Quantity discount available
