MXR Front Hub

The MXR Series of hubs have been built for BMX racing, and have won some of the most prestigious events around the globe.

Wide spoke flanges make the MXR series build into some of the strongest and stiffest wheels in the market whilst sealed cartridge bearings ensure longevity.

At a mere 155g our MXR Front hub is superlight for racing and yet strong enough for freestyle.

The forged alloy body and 15mm hollow alloy axle optimise weight and strength, while minimising flex.

There are two stock bolt configurations:

  • 28H or 32H for Race (with alloy capped Cr-Mo Allen bolts),
  • 36H for Dirt/Street/Park (with Cr-Mo Hex bolts)

(note: the 2 bolt options can be purchased and interchanged, if using pegs we recommend the Cro-Mo Hex bolts).

Specifications

  • Material Forged and CNC machined Aluminium
  • Drillings 28H, 32H and 36H
  • Spoke Hole Circle Diameter (PCD) 45mm both sides
  • spoke hole size (diameter) 2.5mm
  • Centre to Flange Left: 32.5mm, Right: 32.5mm
  • Bearings 2 x 6902 sealed cartridge bearings
  • OLD 100mm
  • Model Ref MXF
  • Colour Black, Red or Polished
Halo MXF BMX Hub shown in red
Halo MXF BMX Hub
Click image to enlarge
Information

To find out where to buy  Click Here

Description Colour Size Wt(g) Part No. Stock Lvl RRP Pack Unit
MXR Front, Front BMX. Sealed Bearing. 100mmx3/8" Bolt-in Axle with alloy covers.Black32H155HUHABF2K£49.99Each
MXR Front, Front BMX. Sealed Bearing. 100mmx3/8" Bolt-in Axle with alloy covers.Red32H155HUHABF2R£49.99Each
MXR Front, Front BMX. Sealed Bearing. 100mmx3/8" Bolt-in Axle
Limited Availability
Blue36H155HUHABF6B£49.99Each
MXR Front, Front BMX. Sealed Bearing. 100mmx3/8" Bolt-in AxleBlack36H155HUHABF6K
ETA: 30th Sep 2020
£49.99Each
MXR Front, Front BMX. Sealed Bearing. 100mmx3/8" Bolt-in AxleRed36H155HUHABF6R£49.99Each
MXR Front, Front BMX. Sealed Bearing. 100mmx3/8" Bolt-in AxleSilver36H155HUHABF6S£49.99Each
MXR Front, Front BMX. Sealed Bearing. 100mmx3/8" Bolt-in Axle with alloy covers.Black28H155HUHABF8K£49.99Each
MXR Front, Front BMX. Sealed Bearing. 100mmx3/8" Bolt-in Axle with alloy covers.Red28H155HUHABF8R£49.99Each
  • Good stock levels
  • Low stock levels, Qtys may not be available
  • +24h Components are available, add 24/48hrs for assembly
  • Special Order Currently non-stock item, contact us for info
  • Out of stock. Expected availability date will be displayed if known.
  • Discontinued. This product is no longer available.
  • M Mixed Quantity discount available
