50cm | 53cm | 56cm | 59cm | 62cm | |
| Horizontal Top Tube (ETT) |
533
|
550
|
570
|
590
|
610
|
| Seat Tube (ST) |
500
|
530
|
560
|
590
|
620
|
| Actual Top Tube C2C (TT) |
533
|
550
|
570
|
590
|
610
|
| Chainstay (CS) |
420
|
420
|
420
|
420
|
420
|
| Bottom Bracket Height/Drop (BBH) |
-72
|
-72
|
-72
|
-72
|
-72
|
| Seat angle (SA) |
76°
|
73.5°
|
73°
|
73°
|
73°
|
| Headtube Angle (HA) |
70.5°
|
71.5°
|
72.5°
|
73°
|
73.5°
|
| Headtube (HT) |
95
|
102
|
125
|
153
|
181
|
| Fork Offset (FO) |
50
|
50
|
45
|
45
|
45
|
| Wheelbase (WB) |
1017
|
1016
|
1023
|
1034
|
1049
|
| Max Tyre (without mudguards) |
32c
|
32c
|
32c
|
32c
|
32c
|
| Max Tyre (with mudguards) |
28c
|
28c
|
28c
|
28c
|
28c
|
NB: Measurements in mm unless otherwise stated.
click here to download the PDF file.
