Vortex 29" Wheels

Built around the traverses of the Enduro World Series our Vortex wheels redefine what Enduro wheels are.

With a generous 33mm internal width Vortex wheels increase tyre volume and maximise the available grip on offer. Using an asymmetric design we have equalised spoke tensions and built a package that leaves descents in its wake, whilst cutting down weight where it isn’t needed for energy sapping climbs. To compensate for the differences in wall length and strength of an asymmetric design, the wall thicknesses have been proportioned to balance out impact forces equally. The Vortex offers offset wheel benefits, without compromise.

At the core of our Vortex wheels are our new and improved instantaneous 120 point pick up MT Supadrive and MT Front hubs, with sealed bearings and super wide spaced flanges for increased stiffness and durability.

100% hand built and pre fitted with tubeless tape, Vortex wheels are tubeless ready from the box.

Coloured decal kits available aftermarket.

Included Fittings

  • Front Standard 100 x 15mm thru
  • Front Boost 110 x 15mm thru
  • Rear Standard 142 x 12mm thru, 135 x 9mm QR
  • Rear Boost 148 x 12mm thru
  • Rear Super Boost 157 x 12mm thru

Vortex Mini Site

Specifications

  • Spokes Black double butted stainless spokes
  • Nipples Black ED coated brass nipples
  • Rim Depth 20.75mm
  • Internal Width 33mm
  • External Width 38mm
  • Rim Joint type Sleeved
  • Front Hub Spacing 100mm or 110mm Boost
  • Rear spacing 135/142mm or 148mm Boost versions
  • Drillings 32H
  • Freehub Shimano HG or SRAM XD versions
  • Freehub Body Alloy
  • Drive System Supadrive
  • Disc Mount 6 Bolt
  • Spoke pattern Front 2X, Rear 3X
  • Recommended Tyre size 2.35-2.8"
  • Tubeless Tubeless ready
  • Colour Stealth Black
Halo Vortex Wheels 29
Halo Vortex Wheels 29"
Click image to enlarge

To find out where to buy  Click Here

Description Colour Size Wt(g) Part No. Stock Lvl RRP Pack Unit
Vortex 29 Front Boost, MT Boost 110 - 15x110mm -Disc Hub,32H, Black DB SpokesStealth Black29"1000WHHAVX9BZ
ETA: 23rd Aug 2020
£164.99Each
Vortex 29 Front, MT Front Disc Hub, 32H (15mm Ft), Black DB SpokesStealth Black29"1055WHHAVX9FZ Low Stock£164.99Each
Vortex 29 Supadrive, MT Supadrive 142Thru/135QR Disc Hub, 32H, Shimano HG, Black DB SpokesStealth Black29"1190WHHAVX9SZ Low Stock£279.99Each
Vortex 29 Supadrive XD, MT Supadrive 142Thru/135QR Disc Hub, 32H, SRAM XD, Black DB SpokesStealth Black29"1190WHHAVX9SZX£279.99Each
Vortex 29 Supadrive, MT Supadrive 157Thru Disc Hub, 32H, Shimano HG, Black DB SpokesStealth Black29"1195WHHAVX9UZ£279.99Each
Vortex 29 Supadrive XD, MT Supadrive 157Thru Disc Hub, 32H, SRAM XD, Black DB SpokesStealth Black29"1195WHHAVX9UZX
ETA: 30th Nov 2020
£279.99Each
Vortex 29 Supadrive Boost, MT Supadrive Boost 148 Disc Hub, 32H, Shimano HG, Black DB SpokesStealth Black29"1200WHHAVX9VZ
ETA: 30th Sep 2020
£279.99Each
Vortex 29 Supadrive Boost XD, MT Supadrive Boost 148 Disc Hub, 32H, SRAM XD, Black DB SpokesStealth Black29"1200WHHAVX9VZX
ETA: 23rd Aug 2020
£279.99Each
  • Good stock levels
  • Low stock levels, Qtys may not be available
  • +24h Components are available, add 24/48hrs for assembly
  • Special Order Currently non-stock item, contact us for info
  • Out of stock. Expected availability date will be displayed if known.
  • Discontinued. This product is no longer available.
  • M Mixed Quantity discount available
